► Input Features

Input channel

16

Input type

Sink/Source

Input voltage rated value

24V DC

Allowed range

0V DC¡«30V DC

Logic 1 signal

15¡«30V DC, allowed minimum current 3mA

Logic 0 signal

0¡«5V DC, allowed maximum current 1mA

Input delay time

<10ms (Rated input voltage)

Isolation mode

Photocoupler isolation

Isolation group

4 groups

Maximum Isolation Voltage

1500VAC

► Physical Features

Dimensions

75mm(L)¡Á90mm(W)¡Á70mm (H)

Weight

<200g

Power

Consumption

+24VDC (Provided by

expansion bus)

0mA

+24VDC (External supply)

80mA

+5VDC (Provided by

expansion bus)

90mA
