MT6300T
-
MT6300T ModelMT6300TMT6300T-CAN¡óPerformance specification¡óDisplay5.7" TFTResolution320*240 pixelsColor65536 colorsBacklightLEDBrightness500cd/m2Backlight life50000 hr.Touch Panel4-wire precision resistance networkProcessor32-bit RISC CPU 520MHzMemory32M FLASH, 64M SDRAMRecipe memory & RTC512KB & RTCExpandable memorySD Card, USB StickPrinter portConnect a printer with a USB port via USB HOST port.Ethernet10/100 Base-TAudio interfaceNoneProgram download1 USB SLAVE portCOM portCOM0:RS232/RS485-2/RS485-4, COM1:RS232/RS485-2/RS485-4;COM2:RS232Video interfaceN/AUSB Host2 USB host ports for keyboard, mouse, printer, and etc.Communication extendingNoneCANopen interface expansion board¡óElectrical specification¡óRated power7.2 WRated voltageDC24VInput rangeDC21¡«DC28VPower down allowed<5msInsulation resistanceGreater than 50M¦¸@ 500V DCDielectric strength test500 VAC 1 minute¡óStructure specification¡óShell colorLight-greyShell materialABSDimensions(mm)204¡Á150¡Á56.7 mmCutout size(mm)192.0¡Á138.0 mmWeight0.96kg¡óEnvironment specification¡óOperating temperature0¡«45¡æOperating humidity10~90% non-condensingStorage temperature-10¡«60¡æStorage humidity10~90% non-condensingShockproof test10~25Hz (X, Y, Z direction, 2G, 30 minutes)Cooling methodNatural air cooling¡óCertification¡óDegree of protectionIP65 (front panel)CE certificationEN61000-6-2:2005 and EN61000-6-4:2007FCC compatibilityComplies with FCC Class A
